1974 Honda CB550 K0

The "Goldilocks" Machine

Not too big, not too small—just right.

Why the "Goldilocks" Bike?

Introduced in 1974 to succeed the CB500 Four, the Honda CB550 hit a legendary sweet spot in Honda's Universal Japanese Motorcycle (UJM) lineup. It combined the lightweight agility of smaller bikes with the smooth, highway-capable power of Honda's flagship CB750.

CB350F / CB400F

Light and agile around town, but struggled to hold effortless 70+ mph cruising speeds on long highway stints.

CB550 Four

The Sweet Spot. Smooth 544cc inline-four, lightweight chassis, near-CB750 power with nimble flickability.

CB750 Four

The original Superbike. Powerful and smooth, but top-heavy and bulky when maneuvering in city traffic.

My History With This CB550

Acquired: [Year you bought it]

I brought this 1974 CB550 into my garage in [Year]. [Share a story here about how you found it—was it in a barn, bought from a collector, or passed down from a family member?]

[Add details about restoration, maintenance, or custom tweaks you've done—e.g., rebuilding the Keihin carbs, polishing the original chrome, or tracking down original four-into-four exhaust pipes.]

Today, it remains one of my absolute favorite bikes to take out on weekend backroad cruises. [Describe how it rides or what makes owning it special to you.]

Maintenance & Restoration Log

A record of repairs, part replacements, tune-ups, and active restoration projects for this 1974 CB550.

Carburetor Overhaul & Synchronization
14,250 mi May 2025 Completed
Ultra-sonic cleaned all four Keihin 22mm slide carburetors. Replaced worn float needles, main jets (#100), and slow jets (#38). Performed bench sync followed by dynamic vacuum gauge sync at idle (1,050 RPM).
Parts & Materials: Keyster Carb Rebuild Kits (x4), OEM Float Bowl Gaskets, Motion Pro Sync Gauge Set.
Front Brake Caliper & Master Cylinder Refresh
14,310 mi Active In Progress
Rebuilding the front single-disc hydraulic brake assembly to fix a sticking piston. Caliper housing stripped and repainted with high-temp engine enamel. Replacing original rubber brake line with stainless braided hose for better lever feel.
Parts & Materials: OEM Caliper Piston & Seal Kit, Stainless Braided Front Brake Line, DOT 4 Fluid.
Electronic Ignition Upgrade (Dyna S)
Future Planned Planned
Plan to swap the factory points and condensers for an electronic Dyna S ignition system to eliminate point bounce and frequent timing adjustments.
Parts Needed: Dynatek DS1-1 Electronic Ignition, Dyna 3.0 Ohm Coils & Spark Plug Wires.

Technical Specifications

Engine 544cc SOHC air-cooled, 8-valve inline-four
Bore & Stroke 58.5 mm × 50.6 mm
Carburetion (4) 22mm Keihin mechanical slide carburetors
Power Output 50 hp @ 8,500 RPM
Transmission 5-speed sequential, wet clutch chain drive
Exhaust System Factory 4-into-4 exhaust with flared tips
Dry Weight 423 lbs (192 kg)
Top Speed 105 – 110 mph
